    • Product description

    For A Better Inspection Scope

    ◆ Model:Osler 2000
    MOHW-MD-No.005547
    ◆ Portable ICG fluorescence imaging system, allowing doctors to inspect lymphatic and blood vessel in ward、consultation or surgical room.
    ◆ Provide doctors with accurate location of blood vessel and lymphatic.
    ◆ Independent Imaging with 3.5 inch screen
    ✔Applicable department : Plastic Surgery、Breast surgery、Dermatology

    ✔A good helper of outpatient / telemedicine / long-term care / surgery room / ward
    Features of ICG Video Scope
    ◆ Monitors edema of lymph in flaps
    ◆ Monitors the Lymphatic reconstruction and the recanalization
    ◆ Distinguishes different lymph drainage of breast and upper limb to decrease the possibility of Lymphedema after surgery
    ◆ Monitors the different pathological changes of muscle by the patients with Lymphedema
    ◆ The Fluorescence Imagining system is highly sensitive and provides reliability to the examination of Vessel Lymphedema
    ◆ Independent imaging with 3.5 inch screen
    ◆ Able to snapshot and record video
    ◆ Provides doctors with accurate location of vessel and lymph

    Case Sharing
    Breast cancer is a very common malignant tumor that women often experience. The number of cases is increasing over the years. In addition, it can seriously threaten women’s physical and mental health. Surgery and operation are still the common treatment that doctors use. However, it can cause detrimental complications to the human body. For example, upper limb lymphedema, bring great pain to the patient and seriously affects the quality of life of the patient. Doctor Cheng Ming-Hui, authority in plastic surgeon and ex-director of Linkou Chang Gung Memorial Hospital, metioned that the fluorescence spectrum lymphangiography of ICG Video Scope can be used in breast cancer, breast augmentation and breast reduction. It brings applications to future clinical studies and reduces the recovery time needed after surgery. It also avoids the waste of medical resources due to the lower possibility of relapse.

    ◆ Price:Call 04-22990512
    ◆ Warranty: A year
    ◆ Provide spare parts for quick repair
    ◆ Made in Taiwan

    Specifications
    Accessory:
    Infrared transmitter: power supplier MPU16A (5V/2.6A) Camera (HDR-CX900): rechargeable batteries (NP-FV50), power supplier, power cable, HDMI cable, USB supported cable, lens hood, lens cap, special filter set.
    Model Osler 2000
    ICG fluorescence imaging system
    Power Supply Voltage 100~240V
    Frequency 50/60 Hz
    Volt-Ampere 13VA
    Size W x H x L 89x76x140mm
    Weight
    730g+915g
    IR Emission Mechine Light source Fluorescent
    Lifie time >50,000hr
    Emission angle 180°
    Usage time
    100 mins
    Charging method Rechargeable/continuously energized
    Video camera
    HDR-CX900    		 Monitor Touch panel
    Brightness control Can be adjusted in multiple stages
    Angle control Open angle：Max90。、Articulation angle：Max270°
    Image stabilization system With dynamic mode (wide angle to telescope)
    Optical SteadyShot、Optical anti-shake image stabilization system
    Focal / exposure / white balance Auto
    Usage time 140mins
    Signal output HDMI、Micro USB、SD card
    Storage Environment Temperature and humidity Temp :- 20~45℃ / RH<60%
    Accessories Rechargeable Battery (NP-FV50)、Power supply、cable、HDMI line、USB cable、Lens hood、
    lens cap、special filter set
    ICG fluorescence imaging system
    View
    Download
    ICG螢光攝影機
    View
    Download





    Model Osler 2000
    Accessory Infrared transmitter: power supplier MPU16A (5V/2.6A)
    Camera (HDR-CX900): rechargeable batteries (NP-FV50),
     power supplier, power cable, HDMI cable, USB supported cable,
    lens hood, lens cap, special filter set
